System overview

1.36 EST3 Installation and Service Manual

(amplifiers). Audio zones are selected manually by the

operator using the LED/Switch displays.

An example of how the page commands work is illustrated in

Figure 1-17. This figure shows a nine story high rise building,

with a fire on the 6th floor. The fire plan requires the evacuation

signal to be sounded on the fire floor, floor above the fire, and

floor below the fire. The alert signal is required to sounded in all

other areas of the building except the stairwells. The first column

(Fire Alarm) shows the automatic responses on the affected

floors according to the fire plan.

Stairwells

9th floor

8th floor

7th floor

6th floor

5th floor

4th floor

3rd floor

2nd floor

1st floor

Alert

Evac

Page

ASU page commands

Fire

Alarm

Alert

Evac

Page to

Evac

All Call

Minus

All Call Zoned

Paging

Alert

Page

Evac

Page

Alert

Evac

Page

Alert

Evac

Page to

Alert

Legend

Fire floor

Floor above or floor below fire

Floor

Figure 1-17: ASU Page Command Example

The Page to EVAC command replaces the EVAC signal with the

Page signal, as shown in the figure’s second column.

The third column shows the Page to Alert command response, all

the Alert signals have been replaced by the Page signal.

The All Call Minus command directs the Page to the areas which

are not receiving the EVAC or Alert signals, i.e. the stairwells.

In the fourth column of Figure 1-17, the stairwells receive the

Page signal when the All Call Minus command is used and do

not automatically receive either the EVAC or Alert signals.
