First the oset value (zero value) is dened („OFFSET“).
The displayed strain gauge value should be in the range
between 50 und 220 mV (typical 130 -170 mV).
Press [SET] to store the actual OFFSET.
ATTENTION: The storage of the value needs
some seconds!
Next step is the calibration of the gain factor for the strain
gauge.
Static load calibration offSet
Static Load Calib.
OFFSET
DMS-Volt: 147 mV
Typ: 130 ... 170 mV
Max: 50 ... 250 mV
SET
Static load calibration offSet - Storage in progreSS
Static Load Calib.
DMS-Volt: 147 mV
Wait max. 20 sec
Static load calibration gain
Static Load Calibration
GAIN
DMS-Volt: 1676 mV
Max: 1509 ... 1989 mV
Load 8kg weight
SET
