• One I/O module, with terminal blocks.
2. Two cables:
• One USB 2.0 cable, Type A male to Type B male, 1.8m (6ft) long.
• One supervisory link cable (30, 50 or 100ft [9, 15 or 30m]), with six wires and
an overall shield.
Note: This supervisory link cable is supplied only when the H201Ti is part of a
Hydran 201Ti RS-485 network, Hydran 201R Model i or is ordered with any Hydran
201Ci Controller.
3. Software and manuals:
• One installation CD-ROM that includes the following items:
- The Hydran Host software.
- Three manuals in PDF format: The Hydran 201i System Instruction Manual
(the present manual), the Hydran 201i System Installation Guide and the
Hydran Host Software Manual.
• One printed Hydran 201i System Installation Guide.
4. One set of tools and accessories:
• One 3/16in (4.75mm) Allen key with a 9in (229mm) T-shape handle (part
number 11817).
• One 5/32in (4mm) Allen key with a short L-shape handle (part number 10013).
• One 7/64in (2.8mm) Allen key with a short L-shape handle (part number
10011).
• One blue protective cap for the H201 sensor.
• One roll of PTFE tape.
7.1.3 Inspecting
Verify the Hydran 201Ti completely as outlined below.
1. Using the shipping list (see Section 7.1.2 above), ensure all items are present.
2. Inspect the following components for any visual damage (bump, scratch or
others):
• The enclosure.
• The brass adaptor.
• The Hydran 201 sensor.
• The CPU module.
• The input/output (I/O) module.
3. Verify the ac power supply voltage (indicated on the left side of the I/O module)
corresponds to the power source voltage and the value on the Test Certificate
