GE HEALTHCARE
DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
Section 8-2 - Software Loading Procedures for BT09 (R8.x.x or later) 8-49
8-2-10-8 Printer Registration (cont’d)
5.) Verify that the user defined printer is added in Printflow View.(Example shown: UP-D21(or 23)MD)
6.) For UP-D50 ONLY:
When performing 4 divided frame print in the active image screen, select D50 for Active Image
Printer.
7.) For UP-D21 or UP-D23:
When upgrading to BT07, updated printer driver may be loaded and assigned. Before assigning
Print Button to Printer, check 'DEVICE' Tab for multiple UP-D21/23 Printer, and check for active
printer.
8.) Right-click on Save.
Figure 8-111 Save
1. Verify
that the
user
defined
printer is
added.
2. SAVE.
For UP-D50
ONLY: Select
D50 for 4
divided frame
print.
To Next Page
