GE HEALTHCARE
DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
8-48 Section 8-2 - Software Loading Procedures for BT09 (R8.x.x or later)
8-2-10-8 Printer Registration
1.) Verify that the power switches of the printer and scanner are turned ON.
2.) Select Utility > Connectivity > Button.
3.) Select the Printer1 button and select the user defined printer which has been recorded in 8-2-6-7
Printer Registration.
4.) Click on >> to add Printflow View.
Figure 8-110 Printer Registration
1. Select the
button the
SONY UP-
D21(or 23)MD
should be
assigned.
2. Select the user defined printer.
3. Click on >>.
To Next Page
