DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
9-50 Section 9-9 - Renewal Parts List For BT04 and BT06
760 PCI CABLE 2389075 MDBRG <-> PC2IP2 1 2
761 TX CABLE ASSY 2305111-3 QCON <-> TRAP 1 2
765 PW SW ASSY 2301858-3
Power Switch, SW Bracket
CB011 (PC2IP BECOMP <-> MDBRG )
1 2
770 FCON Cable Assy 5117485
CB36 (FCON <-> DVD )
CB39 (FCON <-> Removable Bay)
CB37 (FCON <-> OP Panel)
CB38 (FCON <-> OP Panel)
1 2
771 LAMP STAY ASSY 5117796
Lamp Stay Bracket
CB41 (OP Panel <-> Lamp Stay)
12
772 FOOT SW Bracket ASSY 5117795
FOOT SWITCH BRACKET
CB40 (OP Panel <-> Foot SW Connector)
12
- FOOT SWITCH FB200952 Foot Switch (Option) 1 2
- PCG OPTION 2326844 phono microphone (Option) 1 2
- USB SERIALBRIDGE CBL 2304621 Ext. Peripheral <-> L7 1 2
- RS232C CABLE ASSY STRAIGHT 2305549 Ext. Peripheral <-> L7 1 2
- RS232C CABLE ASSY CROSS 2305550-2 Ext. Peripheral <-> L7 1 2
- ECG CBL SHORT 2304616 Ext. Patient <-> L7 1 2
- ECG CBL LONG 2304615 Ext. Patient <-> L7 1 2
-
US CABLE FOR PERIPHERAL
DEVICE
2324360 Ext. Peripheral <-> L7 1 2
- Keyboard Knob Repair kit 2363861 1 2
- Strap with Buckle 5115855 1 2
- Foot for Printer 2318441 1 2
- USB Conversion Adapter 5129258 B Type to A Type in Device room 1 2
- PAT, I/O FA200801 1 2
- MON-CABLE-ASSY 2304171 1 2
4
4D-Mother2 Cable CSL L7
5138724 For 4D Option 1 1
5 4D Box cable Assy CSL L7 5138723 For 4D Option 1 1
6 4D AC cable CSL L7 5147891 For 4D Option 1 1
- Cable Bracket For 4D ECG 5145578 For 4D Option 1 1
- Cable Bracket For 4D non-ECG 5145579 For 4D Option 1 1
- 4D Motor Controller 2372904 For 4D Option 1 1
- Cable, Bracket to Probe 2384183 For 4D Option 1 1
11 Wireless Receiver 5115162 For Voice Scan Option 1 1
Table 9-34 Options, Peripherals and Cables
Item Part Name Part Number Description Qty FRU
