GE HEALTHCARE
DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
9-66 Section 9-10 - Renewal Parts List for BT03 or lower
9-10-4 Plastic Covers (cont’d)
Table 9-43 OP Panel and Keys
Item Part Name Part Numbers Description Qty FRU
251 KB COVER LEFT 2282547 upper left cover of keyboard (under monitor) 1 2
252 KB COVER RIGHT 2282548 upper right cover of keyboard (under monitor) 1 2
253 COVER-TOP 2315418 top cover 1 2
254 KB COVER BOTTOM 2282546 plastic cover under keyboard 1 2
255 UP/DOWN-KNOB-ASSY 2304820 handle for keyboard up/down, wire 1 2
256 ECG CABLE HOOK 2283028 hook under keyboard 1 2
257 FRONT COVER TOP 2304765-2 upper cover around probe connector 1 2
258 FRONT COVER UNDER 2304766-2 lower cover around probe connector 1 2
259 SIDE COVER L ASSY 2304769 plastic cover, including bracket 1 2
260 SIDE COVER R ASSY 2304770 plastic cover, including bracket 1 2
261 SIDE-POCKET 2291872 cover of peripheral room with pocket 1 2
262 SIDE-FRINGE 2303896 cover of peripheral room without pocket 1 2
263 REAR COVER ASSY 2304767-2 plastic cover 1 2
264 REAR DOOR ASSY 2304768 door for peripherals connector, including latch 1 2
265 HANDLE 2309857 rear handle 1 2
266 REAR CONN ASSY 2304618 rear connector for peripherals 1 2
267 REAR CONN 220V ASSY 2304622 rear connector for peripherals 1 2
268 KB BUMPER 2283014 Operation panel bumper 1 2
269 KB BLIND REAR Assy 2304780 Lower cover at Neck portion 1 2
270 KB Rear Assy 2304776 1 2
271 BK Cover Top 2282549 1 2
