GE HEALTHCARE
DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
Section 9-10 - Renewal Parts List for BT03 or lower 9-67
9-10-5 Recording Devices
Figure 9-21 Recording Devices
Table 9-44 Recording Devices
Item Part Name Part Number Description Qty FRU
301 MOD Option Kit
2355070 or
2307450
Either 2355070 (1.3GB drive) or 2307450 (230MB
drive) are available.
11
302 CD-RW-SVC
2375462 (or
2304918)
cd-r/w drive
2375462 includes CD-RW, Ghost CD, and manual.
11
303 FRONT-IF-ASSY 2324098 front connector for peripherals 1 1
303-
2
FRONT CONTROL ASSY 2302393 front connector for peripherals 1 2
304 QCON ASSY 2304617-5 PCON+PSEL+bracket 1 2
305 PAT. I/O FA200801 for ecg 1 1
306 MOD Fixture Kit 2308066 1 2
- DVD unit 2388429-5
Obsolete. Acceptable to use the part if remained in
stock.
--
301
302
303
303-2
304
305
306
307
308
309
310
311
