DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
Section 9-10 - Renewal Parts List for BT03 or lower 9-71
9-10-7 OP Panel and Keys (cont’d)
Table 9-46 OP Panel and Keys
Item Part Name Part Number Description Qty FRU
401 KEYBOARD ASSY 5138507-2
whole keyboard, (Obsolete, Replaced by 5138507-3)
11
401 SVC KEYBOARD L7 5138507-3
whole keyboard, this includes sub-items marked (a),
below
11
402 KEYBOARD ASSY 2267259-2
whole keyboard, this includes sub-items marked (b)
below (Parts no longer supplied. Replaced by
5138507-3)
11
403 ROTARY ENCODER ASSY 2369826
OBSOLETE
(a) Three rotary encoders with cables. Three groups
of encoders with cables and metal stay. In total, there
are 14 encoders in this FRU.
1 1
403 ROTARY ENCODER ASSY 2369826-2
(a) Three rotary encoders with cables. Three groups
of encoders with cables and metal stay. In total, there
are 14 encoders in this FRU. This version contains
two types of LCD brightness adjustment knob and
instruction.
1 1
404 TRACKBALL ASSY 2369823
(a) trackball, two cables w/o bracket
1 1
405 TGC ASSY 2369822
(a) TGC PCB Assy, bracket, cable w/o TGC knobs
11
406 A/N KBD ASSY 2369818
(a) board of a/n key switch
11
407 I/F BOARD ASSY 2369817
(a) I/F PCB ASSY, Mic cable, USB cable
11
408 SW BOARD ASSY 2369815
(a) Three SW PCB Assy, rubber sheets, two cables
1 1
409 KEY ACCESSORY SET 2369816-2
(a) A/N keytops, all encoder knobs, all clear key caps,
labels (For knob repair, order 2363861 repair kit.)
1 2
410 ROTARY ENCODER ASSY 2299448
(b) Three rotary encoders with cables. Three groups
of encoders with cable. In total, there are 14 encoders
in this FRU. (FRU for 2267259-2 keyboard)
1 1
411 TRACKBALL ASSY 2299451
(b) trackball, two cables w/o bracket (FRU for
2267259-2 keyboard)
11
412 TGC ASSY 2299452
(b) TGC PCB Assy, bracket, cable w/o TGC knobs
(FRU for 2267259-2 keyboard)
11
413 A/N KBD ASSY 2299453
(b) board of a/n key switch (FRU for 2267259-2
keyboard)
11
414 I/F BOARD ASSY 2306270
(b) I/F PCB ASSY, Mic cable, USB cable (FRU for
2267259-2 keyboard)
This part no longer available. Order new SVC
Keyboard 5138507-3 for repair.
1 1
415 SW BOARD ASSY 2306273
(b) Three SW PCB Assy, rubber sheets, two cables
(FRU for 2267259-2 keyboard)
1 1
416 KEY ACCESSORY SET 2306274
(b) A/N keytops, all encoder knobs, all clear key caps,
labels (For knob repair, order 2363861 repair kit.)
(FRU for 2267259-2 keyboard)
1 1
- CLEAR KEYCAP & LABEL 2398354-2
Clear Cap and Label set
12
