GE HEALTHCARE
DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
9-72 Section 9-10 - Renewal Parts List for BT03 or lower
Note: How to differentiate the keyboards, 2267259-2 and 2344632-xx:
418 TASK LAMP ASSY 2301853-4
task light
11
419 LAMP ASSY 2301857
Lampstay and cable (inside the L7)
12
420 TASK LAMP KNOB 2304620
knob
1 2
421 LIGHT BULB 2357676
BULB ONLY
1 2
422 CAP 2239428
CAP FOR SCREW HOLE
1 2
- AN KEY RUSSIA 2375159
Only for KBD 5138507-3
12
- AN KEY GREEK 2371160
Only for KBD 5138507-3
12
Table 9-46 OP Panel and Keys
Item Part Name Part Number Description Qty FRU
Keyboard 2344632-xx
Keyboard 2267259-2
The keyboard 2344632-xx “F3” and “F4” contain
“Eject” and “Spooler”.
