Section 9-10 - Renewal Parts List for BT03 or lower 9-77
9-10-9 HDD and Battery (cont’d)
DGPCIO/VIC2
(2372503)
DGPCIO/VIC
(2352289)
PC2IO/VIC
(2301854-2)
BECOMPSW2 (2351329-4 or
later)
OK OK OK
BECOMPSW2 (2351329-3 or
lower)
OK OK
OK
BECOMPSW (2316354-3)
NG NG
OK
BEP3 SV kit (5136903), including:
Part Number Descriptions QTY
5114061 BECOMP3 ASSY LOGIQ7 1
5120441 BECOMP3 UP KIT CABLE ASSY L7 1
5112352 L7 CSL EMC SHILD PL-B 1
5112353 L7 UPG BECOMP3 BASE 1
5112354 L7 UPG BECOMP3 UPR BRKT 1
N9510ZX CAP SCREW 3
N9408HR SCREW (for spare) 6
5122012 HDD Extension Cable1 1
5134920 GHOST CD W2K FOR BEP3 1
5136802 installation instruction (This manual) 1
2367977 DGVIC TRAY2 1
N9306ZX SCREW, HEX SOCKET 3MM, 6MM CAP SCREW 2
U0082AG SPACER MALE/FEMALE 3MM 10 STUD 2
N9306HR SCREW, TP 3X6 2
U0055AG SPACER 2
U0032BA MAGIC TAPE (HOOK) (FOR MODEM) 1 set
U0033BA MAGIC TAPE (LOOP) (FOR MODEM) 1 set
NOTICE
For BEP3 SV Kit ONLY:
This kit may need additional parts depending on the L7 system:
5168551 (R2.5.1 application CD if the system SW level is R2.4.1 or lower) or R3.0.12 (Use FMI72265
if system SW version is still R3.0.8 or lower level on BT03), FMI 72258 DVD Replacement (If CDRW is
mounted on the system), if replacing a BEP1.
