DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
9-82 Section 9-10 - Renewal Parts List for BT03 or lower
9-10-11 Options, Peripherals and Cables (cont’d)
Table 9-50 Options, Peripherals and Cables
Item Part Name Part Number Description Qty FRU
757-
1
BW PNL ASSY 2383135
Front panel of BW Printer for OC 238xxxx(Ver3)
BW Printer Conn Plate (USB/BNC/AC)
AC CB307B (P405 BW PNL <-> Connector P408)
200mm, GND500mm
BNC/Shutter CB042B (P041 BW PNL <-> Rear
PNL P039) 300mm
12
757-
2
BW PNL ASSY 2354668
Front panel of BW Printer for OC 235xxxx/238xxxx
(Ver2/Ver3)
BW Printer Conn Plate (USB/BNC/AC)
AC CB307B (P405 BW PNL <-> Connector P408)
200mm, GND400mm
BNC/Shutter CB042B (P041 BW PNL <-> Rear PNL
P039) 300mm
USB CB042BB(USB BW PNL <-> BECOMP USB)
2000mm
12
757-
3
BW PNL ASSY 2301856
Front panel of BW Printer for OC 22xxxxx/230xxxx
(Ver1)
BW Printer Conn Plate (BNC/AC)
AC CB307B (P405 BW PNL <-> Connector P408)
200mm, GND400mm
BNC/Shutter CB042B (P041 BW PNL <-> Rear PNL
P039) 300mm
12
758 PW SW ASSY 2301858-3
Power Switch
SW Bracket
SW&Cable CB47B (SW <-> MDCON P042) 290mm
1 2
759-
1
DEV ROOM ASSY 2354669-2
AC & shutter panel in device room for OC 235xxxx/
238xxxx (Ver2/Ver3)
Panel (AC/USB/MiniJack)
AC CB306 (P404 DEVroom<-> Rear PNL J407)
900mm, GND900mm
MiniPlug CB042C (P418 DEVroom <-> Rear PNL
J417) 200mm
USB CB042CC (USB DEVroom <-> BECOMP
USB#5) 1000mm
1 2
759-
2
DEV ROOM ASSY 2301859
AC & shutter panel in device room for OC 22xxxxx/
230xxxx (Ver1)
Panel (AC/USB/MiniJack)
AC CB306 (P404 DEVroom<-> Rear PNL J407)
900mm, GND900mm
MiniPlug CB042C (P418 DEVroom <-> Rear PNL
J417) 200mm
1 2
760-
1
FSW CONN ASSY 2383136
Connector on front panel for foot switch for
238xxxx(Ver3)
Panel
CB308A (FSW Conn <-> CB308B P416) 140mm
12
760-
2
FSW CONN ASSY 2301860
Connector on front panel for foot switch
Panel
CB308A (FSW Conn <-> CB308B P416) 140mm
CB308B (J416 CB308A <-> OP Pannel J410) 600mm
12
