GE LOGIQ 7

GE HEALTHCARE
DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
Section 9-10 - Renewal Parts List for BT03 or lower 9-83
761-
1
MONITOR VGA CABLE ASSY 2333352-4
for OC 235xxxx/238xxxx (Ver2/Ver3), including cable,
tie-wrap, and screws.
CB031A (J4 DGVIC <-> Int-housing lock under
monitor CN2) 1820mm
CB031B (CN41 Front Pannel <-> Int-housing lock
under monitor CN3) 600mm
12
761-
2
MONITOR VGA CABLE2 ASSY 2383137
for OC 238xxxx (Ver3)
Speaker CB033A (J7 MDCON <-> Int-housing Lock
under monitor P032) 2250mm
Video CB034 (J5 DGVIC <-> Color Printer
DEVroom R/G/B/Sync) 2500mm
GND CB311 (GND Monitor <-> MainFrame GND)
770mm
AC CB244-1 (SSR2 <-> Monitor AC) 1850mm
BW AC CB307A (J409 Rear AC <-> BW AC Conn
CB307B P408(BW PNL ASSY)) 1250mm
1 2
761-
3
MONITOR VGA CABLE2 ASSY 2359765
for OC 235xxxx/238xxxx (Ver2/Ver3)
Speaker CB033A (J7 MDCON <-> Int-housing Lock
under monitor P032) 2260mm
Video CB034 (J5 DGVIC <-> Color Printer
DEVroom R/G/B/Sync) 2500mm
GND CB311 (GND Monitor <-> MainFrame GND)
770mm
AC CB244-1 (SSR2 <-> Monitor AC) 1850mm
1 2
761-
4
MONITOR VGA CABLE ASSY 2298144
2333352 + 2333877 for OC 22xxxxx/230xxxx (Ver1)
CB031 2333352-3
Speaker CB033 (J7 MDCON <-> Int-housing Lock
under monitor P032) 2360mm
Video CB034 (J5 DGVIC <-> Color Printer
DEVroom R/G/B/Sync) 2500mm
GND CB311 (GND Monitor <-> MainFrame GND)
800mm
AC CB244-1 (SSR2 <-> Monitor AC) 1850mm
1 2
762-
1
OP2 CABLE ASSY 2383139
for OC 238xxxx (Ver3)
HDD Lamp CB26A (P076 BECOMP <-> Int-
housing lock under KBD J014) 1470mm
CB027A (J018 MiniJack BECOMP <-> Int-housing
lock under KBD J017) 1730mm
CB027C (J020 MDCON <-> Int-housing lock under
KBD J017) 1930mm
VGA for LCD CB029A (J022 BECOMP D-Sub <->
Int-housing lock under KBD D-Sub P021) 1570mm
Video CB042A (J040 RearPNL <-> Int-housing lock
under KBD P039) 1970mm
Shutter CB042A (J040 RearPNL <-> Int-housing lock
under KBD J417) 650mm
USB CB025B (USB#1 BECOMP <-> Int-housing
lock in KB support J011) 1810mm
USB CB042BB (USB#3 BECOMP <-> BW-PNL
J420) 1850mm
12
Table 9-50 Options, Peripherals and Cables
Item Part Name Part Number Description Qty FRU
