GE LOGIQ 7

GE HEALTHCARE
DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
9-84 Section 9-10 - Renewal Parts List for BT03 or lower
761-
2
OP2 CABLE ASSY 2359766
for OC 235xxxx/238xxxx (Ver2/Ver3)
HDD Lamp CB26A (P076 BECOMP <-> Int-
housing lock under KBD J014) 1500mm
CB027A (J018 MiniJack BECOMP <-> Int-housing
lock under KBD J017) 1750mm
CB027C (J020 MDCON <-> Int-housing lock under
KBD J017) 2000mm
VGA for LCD CB029A (J022 BECOMP D-Sub <->
Int-housing lock under KBD P021) 1570mm
Video CB042A (J040 RearPNL <-> Int-housing lock
under KBD P039) 2100mm
Shutter CB042A (J040 RearPNL <-> Int-housing lock
under KBD J417) 1600mm
12
762 OP CABLE ASSY 2298145
for OC 22xxxxx/230xxxx (Ver1)
USB CB025A (USB BECOMP <-> Int-housing lock
under KBD J011) 1700mm
HDD Lamp CB26A (P076 BECOMP <-> Int-
housing lock under KBD J014) 1500mm
CB027A (J018 MiniJack BECOMP <-> Int-housing
lock under KBD J017) 1700mm
CB027C (J020 MDCON <-> Int-housing lock under
KBD J017) 2000mm
VGA for LCD CB029A (J022 BECOMP D-Sub <->
Int-housing lock under KBD P021) 1850mm
Video CB042A (J040 RearPNL <-> Int-housing lock
under KBD P039) 2100mm
Shutter CB042A (J040 RearPNL <-> Int-housing lock
under KBD J417) 1600mm
12
763 TX CABLE ASSY 2305111-3 QCON <-> TRAP 1 2
764-
1
PC CABLE2 ASSY 2383140
for OC 238xxxx (Ver3)
CB012 (J10 MDCON <-> Int-housing lock in
BECOMP J006) 480mm
CB012 (J10 MDCON <-> PC2IO D-Sub J2) 620mm
CB014 (J11 MDCON <-> BECOMP Audio mini Jack1
) 270mm
CB016 (Ethernet BECOMP <-> REAN J10) 480mm
USB CB018 (USB#2 BECOMP <-> REAN USB Hub)
700mm
SCSI CB035 (J1 PC2IO <-> REAN J9) 340mm
Modem CB040(J14 REAN <-> Modem Line) 320mm
CB044 (J12 MDCON <-> REST J10) 270mm w/
Ferrite Core
CB047A (J8 MDCON <-> Int-housing lock J042)
1100mm/100mm
1 2
Table 9-50 Options, Peripherals and Cables
Item Part Name Part Number Description Qty FRU
