GE LOGIQ 7

GE HEALTHCARE
DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
9-86 Section 9-10 - Renewal Parts List for BT03 or lower
765-
1
POWER CABLE ASSY 2383142
for OC 238xxxx (Ver3)
CB201 (P2 HV <-> Mother P15, P16, P17) 850mm/
690mm/630mm
CB202 (P1 HV <-> MDCON J18) w/Ferrite Core
480mm
CB205-1 (+6V/0V LV <-> Mother P3, P4 ) w/Ferrite
Core 850mm/850mm
CB205-2 (+6V/0V LV <-> Mother P5, P6 ) w/Ferrite
Core 810mm/810mm
CB206 (-6V/0V LV <-> Mother P7 ) 700mm
CB207 (+5V/0V LV <-> Mother P8 ) 700mm
CB208-1A (+3.3V/0V LV <-> Mother P10 ) 680mm
CB208-2A (+3.3V/0V LV <-> Mother P11 ) 680mm
CB209 (+12V/0V LV <-> Mother P13 ) 700mm
CB210 (-12V/0V LV <-> Mother P12 ) 700mm
CB230-1 (Int-housing lock in KBD <-> Mother P1, P2
) 520mm/540mm
CB231 (Cooling FAN <-> Mother P14 ) 800mm
12
765-
2
POWER CABLE ASSY 2359541
for OC 235xxxx/238xxxx (Ver2/Ver3)
CB201 (P2 HV <-> Mother P15, P16, P17) 950mm/
790mm/720mm
CB202 (P1 HV <-> MDCON J18) 750mm
CB205-1 (+6V/0V LV <-> Mother P3, P4 ) 810mm/
810mm
CB205-2 (+6V/0V LV <-> Mother P5, P6 ) 810mm/
810mm
CB206 (-6V/0V LV <-> Mother P7 ) 700mm
CB207 (+5V/0V LV <-> Mother P8 ) 700mm
CB208-1A (+3.3V/0V LV <-> Mother P10 ) 680mm
CB208-2A (+3.3V/0V LV <-> Mother P11 ) 680mm
CB209 (+12V/0V LV <-> Mother P13 ) 700mm
CB210 (-12V/0V LV <-> Mother P12 ) 700mm
CB230-1 (KBD1 Int-housing lock in KBD <-> Mother
P1, P2 ) 1920mm/1920mm
CB231 (Cooling FAN <-> Mother P14 ) 850mm
12
Table 9-50 Options, Peripherals and Cables
Item Part Name Part Number Description Qty FRU
