GE HEALTHCARE
DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
Section 9-10 - Renewal Parts List for BT03 or lower 9-87
765-
3
POWER CABLE ASSY 2298148
for OC 22xxxxx/230xxxx (Ver1)
CB201 (P2 HV <-> Mother P15, P16, P17) 950mm/
790mm/720mm - non core
CB202 (P1 HV <-> MDCON J18) 750mm
CB205-1 (+6V/0V LV <-> Mother P3, P4 ) 810mm/
810mm
CB205-2 (+6V/0V LV <-> Mother P5, P6 ) 810mm/
810mm
CB206 (-6V/0V LV <-> Mother P7 ) 700mm
CB207 (+5V/0V LV <-> Mother P8 ) 700mm
CB208-1 (+3.3V/0V LV <-> Mother P10 ) 680mm
Contact
CB208-2 (+3.3V/0V LV <-> Mother P11 ) 680mm
Contact
CB209 (+12V/0V LV <-> Mother P13 ) 700mm
CB210 (-12V/0V LV <-> Mother P12 ) 700mm
CB230-1 (Int-housing lock in KBD <-> Mother P1, P2
) 1920mm/1920mm
CB231 (Cooling FAN <-> Mother P14 ) 850mm
1 2
766-
1
BAY CABLE3 2361023-2
CB302A (P401 ATX PS <-> 5 inch Bay J403/J404 )
800mm/220mm
1 2
766-
2
BAY2 CABLE 2401408 CB022A (P001 BECOMP <-> MOD J002) 1500mm 1 2
767-
1
OP2 CABLE2 ASSY 2383141
for OC 238xxxx (Ver3)
CB027B (CN31 OP PNL <-> Int-housing lock under
KBD P017 ) 1090mm
CB029B (CN18 LCD <-> Int-housing lock under KBD
D-Sub P021) 950mm
CB230-2 (CN21 OP PNL <-> Int-housing lock under
KBD Power Cable KBD1) 1000mm
USB CB025A (CN18 OP PNL <-> Int-housing lock in
KB support Assy P011)
CB026B (P014 Int-housing lock in KB support assy <-
> Int-housing lock under KB TRAY P016+P046)
CB308B (CN23 OP PNL <-> Int-housing lock under
KB TRAY P416) 690mm
GND CB312 (T210 OP PNL <-> Main Frame T211)
700mm
CB309B (CN22 OP PNL <-> Int-housing lock KB
TRAY P407B) 690mm
12
767-
2
OP2 CABLE2 ASSY 2359767
for OC 235xxxx/238xxxx (Ver2/Ver3)
CB027B (CN31 OP PNL <-> Int-housing lock under
KBD P017 ) 1130mm
CB029B (CN18 LCD <-> Int-housing lock under KBD
P021) 900mm
CB230-2 (CN21 OP PNL <-> Int-housing lock under
KBD Power Cable KBD1) 1000mm
GND CB312 (T210 OP PNL <-> Main Frame T211)
700mm
12
Table 9-50 Options, Peripherals and Cables
Item Part Name Part Number Description Qty FRU
