GE LOGIQ 7 Service Manual

GE HEALTHCARE
DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
9-88 Section 9-10 - Renewal Parts List for BT03 or lower
767-
3
OP CABLE2 ASSY 2302191
for OC 22xxxxx/230xxxx (Ver1)
USB CB025B (CN18 OP PNL <-> Int-housing lock
under KBD P011) 1000mm
CB027B (CN31 OP PNL <-> Int-housing lock under
KBD P017 ) 1000mm
CB029B (CN18 LCD <-> Int-housing lock under KBD
P021) 900mm
CB230-2 (CN21 OP PNL <-> Int-housing lock under
KBD Power Cable KBD1) 1000mm
GND CB312 (T210 OP PNL <-> Main Frame T211)
700mm
12
768 OP CABLE3 ASSY 2304610-2
CB026C (P016+P046 Int-housing lock under KB
TRAY <-> Front PNL CN44) 130mm
CB026C (P016+P046 Int-housing lock under KB
TRAY <-> Front PNL CN42) 130mm
CB031B (Int-housing lock under Monitor P030 <->
Front PNL CN41) 620mm
1 2
769 PC2IO/IPCABLE ASSY 2304611
for OC 22xxxxx/230xxxx (Ver1)
CB301 (PC2IO <-> PC2IP ) 400mm
1 2
770 SYS AC CABLE ASSY 2304612
CB307A (J408 Int-housing lock under KBD <-> Rear
J409) 1200mm
1 2
771-
1
PWR AC CABLE ASSY 2383138
for OC 238xxxx (Ver3)
CB203 (TB3 SSR <-> HV AC in ) 1050mm
CB212 ( TB3 SSR <-> LV AC in) 1700mm
CB225 (TB2 SSR <-> ATX AC in) 970mm
12
771-
2
PWR AC CABLE ASSY 2304613
for OC 22xxxxx/230xxxx/235xxxx/238xxxx (Ver1/
Ver2/Ver3)
CB203 (TB3 SSR <-> HV AC in ) 1050mm
CB212 ( TB3 SSR <-> LV AC in) 1700mm
CB225 (TB2 SSR <-> ATX AC in) 970mm
CB305 (TB3 SSR <-> Modem AC in) 1150mm
12
772 PC BOX INTERNALCABLE ASSY 2304797
for OC 235xxxx/238xxxx (Ver2/Ver3)
CB101 (J005 BECOMP Mother P-Seq-Jumper <->
Int-housing lock in PC P006) 500mm
CB102 (J105/J045 BECOMP Mother (Reset/HDD) <-
> Int-housing lock as PC BOX J076) 500mm
12
- USB CABLE 2358659-2
CB025AA (USB1 BECOMP <-> OP PNL CN18 )
2600mm
1 2
-
USB DEV CABLE FOR PERIPHERAL
DEVICE
2388600-2
DVD unit - PC Box
CB100 (USB4 BECOMP <-> DVD Drive 5 inch bay
USB ) 1250mm
1 2
778 ECG INT CABLE ASSY 2360884-2 CB030A (Patient I/O <-> DGVIC J8 ) 850mm 1 2
779 PCI CABLE 2389075 CB011 (PC2IP BECOMP <-> MDBRG) 1 2
751 FOOT SWITCH FB200952 Foot Switch (Option) 1 2
756 PCG OPTION 2326844 phono microphone (Option) 1 2
773 USB SERIALBRIDGE CBL 2304621 Ext. Peripheral <-> L7 1 2
774 RS232C CABLE ASSY STRAIGHT 2305549 Ext. Peripheral <-> L7 1 2
Table 9-50 Options, Peripherals and Cables
Item Part Name Part Number Description Qty FRU
