Use
Power On and Power Off
On/Off
The detector can be turned off by using the pressing the black power button for four seconds. The detec-
tor can be turned on by pressing the black power button for one second.
Detector Alignment
To aid in proper alignment of the detector with respect to the X-ray source, there are alignment marks
centered on the front side (imaging side) of the detector. The arrow represents the default head-up dis-
play orientation. See Figure 7-18.
Figure 7-18 Head Up Arrow
Table 7-8 Head Up Arrow
Item Description
1
Head Up Arrow
