GE Optima XR646 - Page 176

Chapter 8: System Hardware Overview
5495975-1EN Rev.9 8-40
© 2013-2017 General Electric Company. All rights reserved.
Grid use in vertical and horizontal position
Table 8-11 Grid Use
Receptor in Vertical Position Grid Line Orientation Grid in Wallstand
Receptor in horizontal Position Grid Line Orientation Grid in Wallstand
