Chapter 8: System Hardware Overview
5495975-1EN Rev.9 8-76
© 2013-2017 General Electric Company. All rights reserved.
Figure 8-57 Wallstand Remote Control Sensor Area
IMPORTANT! The remote must have a direct line of site to the Wallstand Display. Any people or objects
between the remote control and the component will prevent or stop system movement.
You may need to move (e.g., stand to the side of the column) in order to re-establish the
line of sight.
2. Double-click and hold a button to begin movement.
Table 8-16 describes the functions of the remote control.
3. Release the button when desired position is reached.
4. If movement is interrupted, repeat step1 - 3.
