D IRECTION GA091568, R EVISION 5 VIVID E9 S ERVICE M ANUAL
Index - 6 -
leakage current.
too much! 10-32
LEDs
on the DRX board
The GDIF status display 5-46
The Nathan field 5-45
on the GFI board 5-49
on the GRX board 5-42
on the GTX board 5-36, 5-37
on the rear panel 5-75
on the Relay Board 5-40
Left, Right, Front and Back
definition 9-2
legal notes -xi
lighting 2-3
list of abbrevations 9-3
list of effected pages
(revision) -xii
load or reload software
when to... 8-12
loading
application software 8-23
software patches 8-37
system software 8-17
location
enter location 3-27
lock
the LCD monitor 4-14
the top console 4-11
lock ups 7-6
lockout/tagout (LOTO) 1-33
log
site log 4-52
Logoff 4-8
logon as ’adm’ 3-32, 4-15
logs
add bookmark 7-4
LOTO
lockout/tagout 1-33
lower bezel replacement 8-135
lower frame assembly replacement 8-138
lower switch board with elastomer replacement 8-132
lower/raise the top console 4-11
M
M mode 5-15
checks 4-39
main cable cover replacement 8-65
main cable replacement 8-202
main console 5-24
description 5-24
parts replacement 8-190
spare parts 9-52
main controller board replacement 8-108
Main LCD and Touch Screen backlight adjustments 6-5
main power supply 5-77
block diagram 5-78
cables 9-77
parts replacement 8-292
spare parts 9-64
temperature control 5-79
mains cable
inspection 10-8
mains power cables 9-71
mains voltage rating 3-21
maintenance
how often? 10-3
schedule 10-3
manpower
when two persons are needed 8-3
manpower and time requirements
site preparations 2-8
manual overview 1-2
manuals 9-97
mass with monitor and peripherals 3-20
mechanical
functions checks 4-51
safety 1-13
medical waste
regulated 1-33
minimal floor plan suggestion 2-11
model designations 1-6
models covered by this manual 1-3
motherboard (BEP)
expansion slots 5-62
move
the floating top console 4-11
the top console up or down when power is OFF 4-13
the top console when power is OFF 4-12
moving and transporting the ultrasound scanner 4-17
N
network
connectivity
troubleshooting 7-8
setup requirements
InSite requirements 2-12
network printers 5-98
networking setup requirements 2-12
no audio 7-7
no verify 7-9
no video on LCD display 7-7
noise
troubleshooting 7-21
non-disruptive (access via inSite) 5-8
non-magnetic touch latch replacement 8-163
