GEDA 300Z - Technical Data; 3.1 Speeds; 3.2 Drives; 3.3 Assembly height

GEDA
®
300 Z / ZP
Page 14 of 101 Rev.: 001
BL 121 EN Translation of the original operating manual 2011 / 05
3 Technical data
3.1 Speeds
400 V
Travel: (12 m/min.)
In the safety area (0-2 m)
Car control unit (12 m/min. or 9 m/min
#
)
External control unit (12 m/min. or 9 m/min
#
)
Load capacity: Standard operation / assembly 500 kg / 300 kg
230 V
Travel: (12 m/min.)
In the safety area (0-2 m)
Car control unit (12 m/min. or 9 m/min
#
)
External control unit (12 m/min. or 9 m/min
#
)
Load capacity: Standard operation / assembly 300 kg / 300 kg
Safety gear
Triggering speed (22 m/min.)
3.2 Drives
400 V
Power 1.9 kW
Nominal current 4.6 A
Start-up current (max.) 23 A
230 V
Power 1.7 kW
Nominal current 11 A
Start-up current (max.) 31 A
3.3 Assembly height
230 V max. 50 m
3.4 Emissions
Sound power level LWA:
#
9 m/min. may be stipulated by national provisions.
