15.5.2 Dismantling the front wall
 Loosen both bolts (10) on
the front wall (9).
 Raise and remove the front
wall from the base assem-
bly.
15.5.3 Folding up the car
 Remove sprint cotter pin
(1).
 Remove locking pin (2).
 Fold up base assembly (3)
and secure (rope, belt, etc.).
9
10
2
1
3
