3.9.5 Operating materials
Grease: 2.64 lbs (1.2 kg)
Class / quality: NLGI 2
The grease quantity for a lubrication unit is enough for approx.
120 operating hours (3 months/1 shift operation). AGIP GR MU EP or simi-
lar quality of grease. (You must observe the mixing capacity of greases.)
Gear oil:
The motors are lifetime-lubricated. Refilling is not necessary under normal
conditions. In the case of heavy use, the oil must be changed every
10,000 operating hours.
Filling capacity: See the manufacturer's instructions.
Oil types: See gear / motor rating plate.
Contact GEDA before using any other operating materials.
Excess quantities must be returned or disposed of in accordance with
company guidelines and legal requirements.
3.9.6 Electrics
Operating voltage: 400 V / 50 Hz / 3 x 16 A / 3 Ph
230 V / 50 Hz / 1 x 16 A / 3 Ph
Safety class: IP 54 (NEMA 3)
The cables provided by the customer must be designed such that:
they correspond to the connected load of the machine.
no interference voltages or interference frequencies occur.
the response behaviour of the safety equipment meets the relevant
legal requirements.
The necessary cable cross-section must be determined while taking in-
to account the requisite installation type according to DIN VDE 0298
Section 4 and DIN VDE 0100 Section 430. Country-specific regulations
must be observed. A rubber hose coated lead of at least 5 x 2.5 mm²
(or 3 x 2.5 mm² for 230V drive) is required to extend the power cord.
The machine must only be connected to a building site main cabinet
according to IEC 60439-4:2004. Fuse protection min. 16 A / T; residual
current device (RCD) with rated current of max. 0.03 A.
