3.9.4 Stiffener tubes
For certain assembly situations (very large distances to fixing points) it may be necessary
to protect the anchoring tubes against buckling.
Buckling
length
Permissible
pressure
force
400 cm 8030 N
450 cm 6460 N
500 cm 5290 N
550 cm 4410 N
600 cm 3730 N
650 cm 3200 N
700 cm 2770 N
750 cm 2420 N
800 cm 2140 N
850 cm 1900 N
The actual pressure forces in the tube must be calculated us-
ing the forces stated in the tables.
If the specified forces are exceeded, additional measures must
be applied.
The table applies for smooth, one-part steel tubes without joint.
48.3 x 3.25 – St 37-2 DIN 2448 or DIN 2458
