GEDA
®
300 Z / ZP
Page 45 of 101 Rev.: 001
BL 121 EN Translation of the original operating manual 2011 / 05
Securing / designate the bottom
hazard area
If no enclosure is to be used, then
the hazard area around the ma-
chine must be designated and se-
cured appropriately. National regu-
lations on securing / designating
the hazard area must be observed.
Switch cabinets / drive /
control elements
1 = Motor
2 = Cable box
3 = Lubricating device
4 = Safety gear
5 = Sliding carriage switch cabinet
6 = Master switch
7 = Mains power control light
8 = Ramp
4
8
1
2
3
5
6
7
