GeoMax Zoom20 Pro Series User Manual

Zoom20/30/35 Pro | 4Table of Contents
9.3.1 Screen Area 41
9.3.2 Keys, Softkeys and Toolbar 42
9.3.3 Point Symbols 42
10 Applications - Getting Started
43
10.1 Overview 43
10.2 Starting an Application 43
10.3 Selecting the Job 43
10.4 Selecting the Station 44
10.5 Selecting the Orientation 44
10.5.1 Overview 44
10.5.2 Manual Orientation 44
10.5.3 Orientation with Coordinates 45
11 Applications
47
11.1 Common Fields 47
11.2 Survey 47
11.3 Set Out 48
11.4 Resection 49
11.4.1 Starting Resection 49
11.4.2 Measuring Information 50
11.4.3 Computation Procedure 50
11.4.4 Resection Results 50
11.5 Missing Line Measurement 51
11.6 COGO 52
11.6.1 Starting 52
11.6.2 Inverse and Traverse 52
11.6.3 Intersections 53
11.6.4 Offsets 54
11.6.5 Extension 55
11.7 Area & Volume 55
11.8 Remote Elevation 56
11.9 Reference Element - Reference Line 57
11.9.1 Overview 57
11.9.2 Defining the Base Line 57
11.9.3 Defining the Reference Line 58
11.9.4 Subapplication Measure Line & Offset 59
11.9.5 Subapplication Setout 59
11.9.6 Grid Setout 60
11.9.7 Line Segment 62
11.10 Reference Element - Reference Arc 63
11.10.1 Overview 63
11.10.2 Defining the Reference Arc 64
11.10.3 Subapplication Measure Line & Offset 64
11.10.4 Subapplication Setout 65
11.11 Construction 66
11.11.1 Starting Construction 66
11.11.2 Layout 67
11.11.3 As Built Check 67
11.12 Road 2D 68
11.13 Road 3D 69
11.13.1 Starting 69
11.13.2 Basic Terms 70
11.13.3 Creating or Uploading Alignment Files 73
11.13.4 Setout 74
11.13.5 Check 75
11.13.6 Slope Setout 76
11.13.7 Check Slope 78
12 Data Management
79
12.1 Data Management 79
12.2 Exporting Data 79
12.3 Importing Data 80
12.4 Working with a USB Memory Stick 81
12.5 Working with Bluetooth 82
12.6 Working with GeoMax Geo Office and GGO Tools 82
