- System memory ($s) within internal memory
* The switch interrupt information of SW0 and SW1 is written only when the [Output Action]
of a switch is [Momentary] or [Momentary W].
Example: The relationship between the switch output memory setting and the switch
number is shown in the following table.
- n + 5 (ENT0) entry information 0, n + 6 (ENT1) entry information 1
The same contents as n + 0 and n + 1 of the [Info. Output Memory] that is set in the entry
mode are written. Write operation occurs when the [ENTER] key is pressed in the entry mode.
When the entry selection has changed, write operation will not occur.
When (n + 5) entry information 0 is read by the host, writing completed bit (bit 15) is reset.
Data is written in the backup (escape) area before it is read. (Refer to page App6-19.)
Output Memory Switch No.
$s 080-00 0
$s 085-10 90
$s 095-15 255
Address Contents
000 Screen number
001
002 Overlap 0 Status 0: OFF 1: ON
003 Overlap 1 Status 0: OFF 1: ON
004 Overlap 2 Status 0: OFF 1: ON
080 Universal serial port switch output 0 Output code 0 - 15
081 Universal serial port switch output 1 Output code 16 - 31
082 Universal serial port switch output 2 Output code 32 - 47
083 Universal serial port switch output 3 Output code 48 - 63
084 Universal serial port switch output 4 Output code 64 - 79
085 Universal serial port switch output 5 Output code 80 - 95
086 Universal serial port switch output 6 Output code 96 - 111
087 Universal serial port switch output 7 Output code 112 - 127
088 Universal serial port switch output 8 Output code 128 - 143
089 Universal serial port switch output 9 Output code 144 - 159
090 Universal serial port switch output 10 Output code 160 - 175
091 Universal serial port switch output 11 Output code 176 - 191
092 Universal serial port switch output 12 Output code 192 - 207
093 Universal serial port switch output 13 Output code 208 - 223
094 Universal serial port switch output 14 Output code 224 - 239
095 Universal serial port switch output 15 Output code 240 - 255
