HEIDENHAIN iTNC 530 291
8.6 Programming Examples
7 L Z+250 R0 FMAX M6 Tool change
8 TOOL CALL 2 Z S4000 Call tool: drill
9 FN 0: Q201 = -25 New depth for drilling
10 FN 0: Q202 = +5 New plunging depth for drilling
11 CALL LBL 1 Call subprogram 1 for the entire hole pattern
12 L Z+250 R0 FMAX M6 Tool change
13 TOOL CALL 3 Z S500 Call tool: reamer
14 CYCL DEF 201 REAMING Cycle definition: REAMING
Q200=2 ;SETUP CLEARANCE
Q201=-15 ;DEPTH
Q206=250 ;FEED RATE FOR PLNGN
Q211=0.5 ;DWELL TIME AT DEPTH
Q208=400 ;RETRACTION FEED RATE
Q203=+0 ;SURFACE COORDINATE
Q204=10 ;2ND SETUP CLEARANCE
15 CALL LBL 1 Call subprogram 1 for the entire hole pattern
16 L Z+250 R0 FMAX M2 End of main program
17 LBL 1 Beginning of subprogram 1: Entire hole pattern
18 L X+15 Y+10 R0 FMAX M3 Move to starting point for group 1
19 CALL LBL 2 Call subprogram 2 for the group
20 L X+45 Y+60 R0 FMAX Move to starting point for group 2
21 CALL LBL 2 Call subprogram 2 for the group
22 L X+75 Y+10 R0 FMAX Move to starting point for group 3
23 CALL LBL 2 Call subprogram 2 for the group
24 LBL 0 End of subprogram 1
25 LBL 2 Beginning of subprogram 2: Group of holes
26 CYCL CALL 1st hole with active fixed cycle
27 L IX+20 R0 FMAX M99 Move to 2nd hole, call cycle
28 L IY+20 R0 FMAX M99 Move to 3rd hole, call cycle
29 L IX-20 R0 FMAX M99 Move to 4th hole, call cycle
30 LBL 0 End of subprogram 2
31 END PGM SP2 MM
