364 Programming: Miscellaneous Functions

10.4 Miscellaneous Functions for Contouring Behavior

Example NC blocks

5 TOOL CALL 20 ...

Tool with large tool radius

...

13 L X... Y... R... F... M97

Move to contour point 13

14 L IY-0.5 ... R... F...

Machine small contour step 13 to 14

15 L IX+100 ...

Move to contour point 15

16 L IY+0.5 ... R... F... M97

Machine small contour step 15 to 16

17 L X... Y...

Move to contour point 17
