HEIDENHAIN iTNC 530 665
18.1 General User Parameters
KinematicsOpt: Maximum permitted
deviation from entered calibration sphere
radius
MP6601
0.01 to 0.1
KinematicsOpt: M function for positioning
rotary axes
MP6602
Function inactive: -1
Position the rotary axis with a defined miscellaneous function: 0 to 9999
TNC displays, TNC editor
Cycles 17, 18 and 207:
Oriented spindle stop
at beginning of cycle
MP7160
Oriented spindle stop: 0
No oriented spindle stop: 1
Programming station MP7210
TNC with machine: 0
TNC as programming station with active PLC: 1
TNC as programming station with inactive PLC: 2
Acknowledgment of
POWER INTERRUPTED
after switch-on
MP7212
Acknowledge with key: 0
Acknowledge automatically: 1
ISO programming: Set
the block number
increment
MP7220
0 to 150
Disabling the selection
of file types
MP7224.0
All file types selectable via soft key: %0000000
Disable selection of HEIDENHAIN programs (soft key SHOW .H): Bit 0 = 1
Disable selection of DIN/ISO programs (soft key SHOW .I): Bit 1 = 1
Disable selection of tool tables (soft key SHOW .T): Bit 2 = 1
Disable selection of datum tables (soft key SHOW .D): Bit 3 = 1
Disable selection of pallet tables (soft key SHOW .P): Bit 4 = 1
Disable selection of text files (soft key SHOW .A): Bit 5 = 1
Disable selection of point tables (soft key SHOW .PNT): Bit 6 = 1
Disabling the editor for
certain file types
Note:
If a particular file type is
inhibited, the TNC will
erase all files of this type.
MP7224.1
Do not disable editor: %0000000
Disable editor for
 HEIDENHAIN programs: Bit 0 = 1
 ISO programs: Bit 1 = 1
 Tool tables: Bit 2 = 1
 Datum tables: Bit 3 = 1
 Pallet tables: Bit 4 = 1
 Text files: Bit 5 = 1
 Point tables: Bit 6 = 1
3-D touch probes
