HEIDENHAIN ITNC 530 - CONVERSATIONAL PROGRAMMING User Manual

664 Tables and Overviews
18.1 General User Parameters
Coordinates of the TT 120 stylus center
relative to the machine datum
MP6580.0 (traverse range 1)
X axis
MP6580.1 (traverse range 1)
Y axis
MP6580.2 (traverse range 1)
Z axis
MP6581.0 (traverse range 2)
X axis
MP6581.1 (traverse range 2)
Y axis
MP6581.2 (traverse range 2)
Z axis
MP6582.0 (traverse range 3)
X axis
MP6582.1 (traverse range 3)
Y axis
MP6582.2 (traverse range 3)
Z axis
Monitoring the position of rotary axes and
parallel axes
MP6585
Function inactive: 0
Monitor axis positions, definable bit-coded for each axis: 1
Defining the rotary axes and parallel axes to
be monitored
MP6586.0
Do not monitor the position of the A axis: 0
Monitor the position of the A axis: 1
MP6586.1
Do not monitor the position of the B axis: 0
Monitor the position of the B axis: 1
MP6586.2
Do not monitor the position of the C axis: 0
Monitor the position of the C axis: 1
MP6586.3
Do not monitor the position of the U axis: 0
Monitor the position of the U axis: 1
MP6586.4
Do not monitor the position of the V axis: 0
Monitor the position of the V axis: 1
MP6586.5
Do not monitor the position of the W axis: 0
Monitor the position of the W axis: 1
KinematicsOpt: Tolerance limit for error
message in Optimization mode
MP6600
0.001 to 0.999
3-D touch probes
