Herma 500 - Dispensing Systems; Dispensing Beaks; 15° Angled Dispensing Beak; Pivot Beak; Application Unit

Function
34 1.10 GB (2019/02/28)
Dispensing Systems
Dispensing beaks
The following dispensing beak designs are available:

Simple dispensing plate
 Dispensing beak with roller
 Dispensing beak with spring-loaded roller
 Dispensing beak with brush
 15° angled dispensing beak
NOTICE: For all dispensing systems, make sure that the label web is fed in a straight line (touching the paper
guides).
When using a dispensing beak with an application roller, make sure that the distance between the application roller
and dispensing plate is less than one label length.
15° angled dispensing beak
Guide the label web under the retaining plate.
Adjust the retaining force so that the label web passes through easily but with noticeable resistance.
Pivot beak / application unit
NOTICE: Make sure that the distance between the application roller and dispensing plate is less than one label
length.
