Inputs/Outputs (X19), Additional Signals
This optional connection provides inputs/outputs for external control (e.g. PLC).
Pin Designation || I/O || Description || Colour || On circuit board 70039292
1 +24V || Out || Voltage supply (< 150 mA) || Brown || X39.1
2 Gnd || I/O || Earth (all DC voltages) || Blue || X39.2
3 EncA || Out || User defined || White || X39.3
4 Feed || In || Manual dispensing || Green || X39.4
5 Stop || In || Label sensor (end of transfer) || Pink || X39.5
6 Start || In || Applicator start || Yellow || X39.6
7 Syn1 || In || User defined || Black || X39.7
8 Ack-o || Out || Acknowledgement || Grey || X39.8
9 Lock || In || Lock applicator start (1 – active) || Red || X39.9
10 No_Label || Out || Label missing on backing paper || Purple || X39.10
11 Feeding || Out || Label transfer under way || Grey-pink || X39.11
12 Feed || Out || User defined || Red-blue || X39.12
For the pin assignments of the connections, please refer to the separate
wiring diagram.
Inputs/Outputs (X9), Industrial Ethernet
This optional connection provides inputs/outputs for industrial Ethernet applicators.
Pin Designation || I/O || Description || Colour || On circuit board 70039292
1 +24V || – || Voltage supply (<150 mA) || Brown || X39.1
2 Gnd || – || Earth (all DC voltages) || Blue || X39.2
3 EncA || Out || User defined || White || X39.3
4 Ack || In || Acknowledgement || Green || X30.1
5 Stop || I/O || Label sensor (end of transfer) || Pink || X39.5
6 Start || In || Applicator start || Yellow || X39.6
7 Syn1 || In || Syn1 || Black || X39.7
8 Ack_o || Out || Acknowledgement || Grey || X39.8
