Documentation HERMA 500
1.10 GB (2019/02/28)
91
Off: Anticlockwise (choose this setting on the unwinder/winder in version L, on the loop
module and the magazine filler in version R)
If you change the rewinder’s direction of rotation using DIP switch 8, the
change does not take effect until you teach in the angle sensor again (see
“Teaching in the angle sensor (motorised unwinder/rewinder)”).
After you change the direction of rotation, you also have to rotate freewheel 1 by 180°! When installing the
freewheel, make sure it is horizontal so that the cover can close.
FS03 Sensor
Label Material, Minimum Requirements
The gap between the labels must have the following dimensions, depending on the applicator speed:
Applicator speed // Width of gap between the labels
40m/min • 1,600"/min
