Documentation HERMA 500
1.10 GB (2019/02/28)
51
The applicator may not be used in explosive atmospheres.
Properly mount the applicator before power is applied.
Installation/removal may only be performed by trained specialists when the applicator is disconnected from the
power supply. Properly mount the applicator and put the protective covers back on before applying power.
If this information is not observed, people involved in transport and third parties could be seriously injured.
Use only in dry areas
Only use the machine in dry areas.
The machine must be installed in a stable position where it cannot slip.
Mount the applicator using the two mounting holes for round rods (2), Ø 30mm, hole spacing: 182mm.
Properly secure the mounting system on the rods, e.g. using a clamping screw (3), a washer (4) or the
optional fine-adjustment device (5).
