4.31 Central Braking System—P3700B Model Only
Chapter 4: Removal, Replacement, and Adjustment Procedures
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 4 - 79
Service Manual (MAN272 REV 4)
4
17. Repeat step 3 through step 17 for the opposite side.
18. Remove the detent mechanism assembly (T) from the cross channel.
19. Slide the brake rod support bracket (O) and bushing (U) from the end of the
brake/steer pedal (A).
20. Remove the brake strips (K and V) from the base frame.
Replacement
1. To install the replacement central braking system mechanism, reverse the
removal procedure with attention to the following:
a. Ensure that the brake/steer strip (straight metal strap) and the brake
strip (bent metal strap) are correctly assembled on their respective
sides.
b. Ensure that the brake strips (K and V) are correctly attached to its cam
pivots.
c. Complete sections “Brake and Steer Caster Adjustment” on page 4-81
and “Brake Caster Adjustment” on page 4-82.
2. Ensure that all brake and steer functions work properly.
3. Do the “Function Checks” on page 2-4.
