1. On the measurement screen, press to dis-
play the screen for selecting the data to be saved.
2. Select a panel number for saving data. (Select a
panel with "No Data" indicated.)
If a panel is not displayed on the screen, press
to display the page showing the
desired panel.
Note that if the selected panel already contains
data, the existing data will be overwritten by new
data.
When a panel number is selected, a panel save
confirmation screen then appears.
3. Press and enter a panel name.
Entering a panel name enables data to be easily
identified when read out later.
If no panel name is entered, the panel is automati-
cally assigned a name consisting of the selected
panel number followed by "Data"
(e.g., " ")
See For details of the method of assigning a panel
name:"Registering an Equipment Name/Control
Number" (p. 50)
Press to save the data and return to the previous screen.
Press to return to the previous screen without saving the data.
Press to display a screen for selecting panel
numbers where measurement conditions are saved.
