Hioki ST5540 - Measurement Examples; Earth Leakage Current Measurement

6.3 Measurement examples
83
6
Chapter 6 Measurements
1. Connect the instrument and the equipment under test.
See "3.3 Connecting equipment under test to the instrument" (p. 36)
2. During manual measurements, Earth leakage current measurement starts upon returning to the
measurement screen.
Measurement conditions can be changed during measurement.
See "6.1 Making manual measurements" (p. 79)
During automatic measurements, becomes available upon return to the measurement
screen. Press to start
Earth leakage current measurement.
See "Chapter 4 Settings" (p. 47)
Only is available during automatic measurements.
6.3 Measurement examples
Earth leakage current measurement
1
2
