10.14 Measurement Networks
276
Network G is a measurement network that complies with IEC 61010-1.
The G measurement network has the following circuit configuration.
Network G (for IEC61010-1)
Network (875 k) with 875 
375 ± 1%
0.22 F± 2%
500 ± 1%
Applicable standards IEC 61010-1:2010
Safety requirements for electrical equipment used in measure-
ments, control and laboratories
Current measurement circuits for testing in damp conditions
Measurement circuit configuration Basic measurement element : 375  + 500 
Filter configuration ON setting : 375 , 500  and 0.22 F networks
(when input protection fuse is short-circuited)
Element tolerance Resistance: ± 1%
Capacitor : ± 2%
