10.14 Measurement Networks
277
8
9
Chapter 10 Specifications
10
This is a network for measuring protective conductor current.
Protective conductor current has the following circuit configuration.
This network can be used to conduct leakage current tests in compliance with
applicable standards.
Protective conductor current network
Network (35 ) with 35
35 ± 1%
Measurement
circuit configuration
Network with 35
Impedance : 35 (0.5% (DC to 1 MHz))
(when protection fuse is short-circuited)
Element tolerance Resistance : ± 1%
