7.14 Setting the Backlight
136
The backlight of the LCD panel on the front panel can be set to Constant ON or Auto OFF.
When a PC is connected for measurement control and the instrument display is not used, the backlight is
turned off to prolong the service life of LCD parts and save energy.
(Backlight service life expectancy : Approx. 10,000 hours, as estimated by the manufacturer)
7.14 Setting the Backlight
1. Press on the initial screen to display the system screen.
2. Press to display the backlight setting screen.
3. Set the backlight control mode.
Keeps the backlight turned on at all times.
Automatically turns off the backlight after a
preset time.
Backlight setting screen
When the backlight control mode is set to “Auto OFF,” the DANGER lamp will
blink while the backlight is off.
To Next Page
