2.1 Instrument Labels and Functions
26
Used to carry the instrument.
1. Handle
Used to tilt the instrument.
2. Stand
Take the following precautions to prevent electric shock accidents and damage
to the instrument.
• Use M3 screws to attach rack mount brackets after removing the feet.
• When the rack mount brackets are removed to restore the instrument to its
original condition, be sure to use the original screws.
• The screws used must not penetrate more than 5 mm below the metal panels.
• Do not apply heavy downward pressure with the stand extended. The stand
could be damaged.
