5.1 Connecting the Test Lead
78
Position the test lead on the enclosure or terminal of the equipment under test to measure leakage cur-
rent. When using two or three lead wires, alligator clips may be used to ensure a secure connection.
Detach the pin lead from the tip of each L2200 Test Lead and insert the included alligator clip.
]
Using Alligator Clips (when using two or three test leads)
Pin leads and alligator clips can be connected to either end of the connection
cord.
