10.10 PC Interfaces
265
8
9
Chapter 10 Specifications
10
RS-232C interfaces
Communication content : Remote control, Measurement value output
Transmission system
: Synchronous communication, full duplex
Transmission speed
: 9,600 bps, fixed
Data bit length
: 8 bits, Stop bit : 1, Parity bit : None
Delimiter
: CR+LF
Handshake
: None
XON/XOFF
: Not used
Connector
: D-sub 9-pin, male, connector retaining screws (#4-40)
USB interfaces
Communication content : Remote control, Measurement value output
Conforms to USB V1.1 (RS-232C conversion, 9600 bps)
Connector : Series A receptacle
10.10 PC Interfaces
10.11Printer
The 9442 Printer (option) is required for printing measurement data.
Printer output RS-232C interface terminal used
Printer, printer cable, AC adapter and printing paper are separately sold
Printed
information
Date of measurement (2009/10/01)
Equipment name (ELECTRIC-123)
Control number (123456789012)
Network (B)
Class ( I, II, Internal)
Applied part (B, BF, CF) only network B1 and B2
Measurement mode
(Earth leakage current,
Enclosure leakage current, and so on)
Filter setting (ON, OFF)
Target current (AC, DC, AC+DC, ACPeak)
Allowable value (1.000 mA)
Maximum value (0.567 mA)
Judgment result (PASS/FAIL/LOW)
Power supply polarity (Positive phase, Negative phase)
Equipment status (Normal, Disconnected
grounding wire, and so on)
S10, 12, 13 test results*
Information to be printed can be selected from the items above.
All data is printed in English
*
only ST5540
