4.1 Selecting a Network
48
4.1 Selecting a Network
• The instrument normally functions as an ammeter, but will operate as a volt-
meter when "voltmeter" is selected in the mode setting screen.
When the network configuration not supported by networks A to G is required,
your own network can be connected for testing by using the instrument as a
voltmeter.
See "7.1 Setting the Mode (To use the instrument as a voltmeter)" (p. 117)
• Once a network is selected, the initial screen appears the next time power is
turned on. If turning the power switch off with the measurement screen dis-
played, the measurement screen is redisplayed the next time power is on.
1. After the power switch of the HiTESTER is set to ON ( ), the initial screen appears.
2. Press and then display the network select screen.
Press the to switch the network selection screen.
3. After the desired network is selected, the initial screen appears.
To change the network, return to the network select screen by pressing the key.
Network select screen 1
Network select screen 2
Initial screen
To Next Page
