Chapter 9 External Control
Make a connection to the EXT I/O connector to perform external control.
(1) EXT I/O terminal functions
Input of start/stop signals
Selection of panel number for data loading
Output of measurement end signal
Output of comparator judgement signal
Others
(2) Connector type
57RE-40360-730B(D29)-FA (manufactured by DDK)
(3) Mating connector
57F-30360-20S (manufactured by DDK)
RC30-36P(50) (manufactured by Hirose Electric) or equivalent instrument
(to be procured by the user)
External Control Chapter 9
EXT I/O connector pin layout (on main instrument)
