Hioki ST5540 - Chapter 8 Controlling the; USB Interface)

139
8
Chapter 8 Controlling the Instrument From a Computer
This chapter contains information relating to the RS-232C and USB interfaces, and uses the fol-
lowing symbols to identify which information is relevant to each interface.
Sections without these symbols pertain to both interfaces.
: RS-232C only
: USB only
Before Use
• Always be sure to secure the RS-232C cable to the interface connector
by tightening up the fixing screws.
• Be sure to input commands with data in the designated format.
The customer needs the following cable to connect the instrument.
USB CABLE: (USB B connector to USB A connector)
Overview and Features
• All functions except for the power switch and self-test functions can be
controlled via RS-232C/USB.
• The instrument can be reset.
Controlling the Instrument
From a Computer
(RS-232C,
USB interface) Chapter 8
USB
This USB interface provides communications capability only and no storage
capacity.
