8.7 Command Message Description
166
Error
In Touch current : Enclosure - Line or Enclosure - Line leakage current, if the
pre-check performed to prevent a ground fault results in NG judgement, an
equipment-dependent error occurs.
All situations other than 1, 2, 3, 4, and 5 result in an execution error.
1. When the mode is set to "leakage current mode"
2. When network A, D, E, or F is selected
Measurement modes : Enclosure - Line leakage current
Measurement method : Manual measurement
When application line setting is an internal contact
3. When network B1 is selected (only ST5540)
Measurement modes : Enclosure - Earth leakage current
Enclosure - Enclosure current
Patient leakage current II
Patient leakage current III
Free current
Measurement method : Manual measurement
In single fault condition (application of 110% of rated voltage)
4. When networks Cor G are selected
Measurement modes : Touch current:Enclosure - Line
Measurement method : Manual measurement
When application line setting is an internal contact
5. When network B2 is selected (only ST5540)
Measurement modes : Touch current : Enclosure - Earth
Touch current : Enclosure - Enclosure
Patient leakage current : SIP/SOP
Total patient leakage current:SIP/SOP
Free current
Measurement method : Manual measurement
Other test condition
(application of 110% of rated voltage)
Measurement modes : Patient leakage current : F-type applied part
Patient leakage current : Metal accessible part
Total patient leakage current : F-type applied part
Total patient leakage current : Metal accessible part
Measurement method : Manual measurement
Special test condition
(application of 110% of rated voltage)
Sets and queries the voltage application ON/OFF
Executes calibration.
Syntax
Command
:CALibration
Function
Command Executes calibration.
Example
Command
:CALibration
Executes calibration.
Error
• An execution error occurs in the following cases :
• When frequency range is set to 15 Hz
• When measured current is set to something other than AC or AC + DC
• When mode is "Protective conductor ammeter mode"
• When mode is "Leakage current tester mode" and the following also applies
Network other than Network B2
When measurement mode is not selected
When measurement method is set to "automatic measurement"
