8.7 Command Message Description
168
Numerical value1
Numerical value2
Example
Command
:CONFigure:AUTO:KIND 97,0
Sets the type of automatic measurement as follows:
Equipment under test status: Normal condition
Power supply polarity: Positive phase, Negative phase
Query
Response
:CONFigure:AUTO:KIND?
:CONFIGURE:AUTO:KIND 99,0 (Headers: ON)
99 (Headers: OFF)
The type of automatic measurement has been set as follows:
Equipment under test status: Normal condition, Disconnection of one wire in
power line
Power supply polarity : Positive phase,Negative phase
Error
An execution error occurs in the following cases:
• When the measurement method is set to "manual measurement"
• When the measurement mode is not selected
• If the set numeric value is not within the specified range(Command)
• When a mode other than "leakage current mode" is set
• In automatic measurement(Command)
Queries the type and setting of automatic measurement
128 64 32 16 8 4 2 1
bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0
Not used
Negative
phase
Positive
phase
Single-fault
condition
Application
of 110%
voltage
(
Negative
phase
)
Single-fault
condition
Application
of 110%
voltage
(
Positive
phase
)
Single-fault
condition
Disconnec-
tion of pro-
tective
earth con-
ductor
Single-fault
condition
Discon-
nection of
one wire in
power line
Normal
32768 16384 8192 4096 2048 1024 512 256
bit 15 bit 14 bit 13 bit 12 bit 11 bit 10 bit 9 bit 8
Not used Not used Not used Not used
Application
of line
voltage N
Application
of line
voltage L
AC
DC
128 64 32 16 8 4 2 1
bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0
Not used
Not used
Specific
110%
voltage
application
(
Negative
phase
)
Specific
110%
voltage
application
(Positive
phase
)
Not used
Other 110%
voltage
application
(
Negative
phase
)
Other 110%
voltage
application
(
Positive
phase
)
Other 110%
voltage
application
(none)
32768 16384 8192 4096 2048 1024 512 256
bit 15 bit 14 bit 13 bit 12 bit 11 bit 10 bit 9 bit 8
Not used Not used Not used Not used Not used Not used Not used Not used
